Philips DVP3345VB - Manual (Page 22)

EN - 22
English 22 VCR Recording Options Videotape Recording
Read and follow the steps below to record a television program onto a
videotape.
Before you begin :
● This DVD/VCR does not have a tuner input jack. To record TV
programs on your DVD/VCR, you need to connect this DVD/VCR
to an external tuner device (e.g., set top box, cable box or satellite
receiver) that has audio/video output jacks. See page 10 on how to
connect the DVD/VCR to the external tuner.
● Make sure the DVD/VCR is in VCR mode. Press VCR so VCR light appears
on the front of the DVD/VCR.
Recording Prevention
Video cassettes have record tabs to ensure that recordings are
not accidentally erased.
● To prevent recording,break off the tab with a screwdriver.
● To allow recording,cover the hole with clear tape.
1
Turn on your external tuner, and turn on the TV and set it to
the correct Video In channel. (Check your TV owner’s manual for
details.)
2
Insert a tape with its record tab intact into the cassette
compartment of the DVD/VCR. If tape playback begins, press STOP C.
3
Press SPEED repeatedly until the desired tape speed (SP or
SLP) appears briefly on the screen. Details about tape speed are on
page 58.
4
Press INPUT to select the appropriate external input channel
(L1/L2) to which your external tuner is connected. Then select
the desired channel to record on the external tuner.
5
Press REC I to start recording. “REC” will appear on the DVD/
VCR’s display panel.
● To pause the recording, press PAUSE F once. “REC” will flash. To
resume recording, press REC I or press PAUSE F again. “REC” will
reappear.
● To stop recording, press STOP C.
DVD VCR SETUP
INPUT MENU
REC SPEED MODE
ANGLE SEARCH REPEAT
DISPLAY SUBTITLE ZOOM
TIMER SET
REPEAT
A-B
AUDIO
BACK PAUSE STOP
PLAY
OK
FFW REW
CLEAR TITLE
DISC
TRACKING
OPEN/CLOSE
1 2
6 5 4
7 8 9
0 +10
3
Helpful Hint
• Other recording options are on
pages 23-29.
• The VCR will record in a preset
volume.
• Pause will switch to stop after 5
minutes to protect the VCR and the
tape from damage. When a recording
is paused, review the pause time
remaining with the C marks on the
screen. Each C mark equals 1 minute
remaining. During the last minute of
paused recording, the C mark will
flash.
• If any menu is on the TV screen, REC I
on the remote does not function. Press
CLEAR to remove the menu. Then,
press REC I. Or, use REC I on the
front of the DVD/VCR.
1
Turn on the TV.
2
Insert a tape in the DVD/
VCR.
4
5
3
Remove the tab
to prevent
recording.
Cover the hole
to allow
recording.
E8E2CCD_E8E2CCH_EN_v1.book Page 22 Friday, March 9, 2012 6:37 PM
