LEDs
LNE100TX EtherFast 10/100 Network Card
LINK The card has been successfully connected to
a live port on a hub or switch
ACT Denotes the card’s activity. Network packets
are being transmitted or received when this
LED is flickering
100 When ON, the card is operting at 100Mbps
When OFF, the card is operating at 10Mbps
FDX When ON, the card is operating at a maxi
mum throughput of 200 or 20Mbps;
When OFF, the card is operating in half
duplex at a speed of either 100 or 10Mbps
EFAH05W EtherFast 10/100 Auto-Sensing
5-Port Workgroup Hub
POWER Indicates that the hub is receiving power.
100/10COL Indicates if collisions are being encountered
at 100Mbps and/or 10Mbps.
100 ON if a given port is operating at 100Mbps;
off if the port is running at 10Mbps.
LINK/ACT ON or flickering if a given port is sending or
receiving data; off if the port is not con-
nected to a node.
SW ON if uplink port is in 100Mbps/100 meter
Distance Extender mode. All connections on
the hub must be running at 100Mbps.
Appendix
66
