Building Safety. Building Security.

Description

• ADM loop technology with

System Sensor/200 protocol

• Long lifetime of strobe due to the use

of LEDs

• Low power consumption
• Versions with or without integrated

dual-isolator available

• Various base types available –

IP24, IP44, IP65

Specifi cations

Operating voltage

Supply through loop voltage

Flash frequency

1Hz

Ambient temperature

-25°C to +70°C

Dimensions ш Ч H

112 × 37 (mm) (incl. base LPBW)

Weight

80g

Colour

red

The loop powered strobe is fi tted into a round, red plas-

tic case. It is powered and actuated as a module via the

ADM loop with System Sensor/200 protocol.

The address of the strobe is selected with two decadic

rotary switches located at the bottom of the device.

The strobe is designed for indoor or outdoor wall moun-

ting. For this purpose a special base is needed. Various

base types for protection classes IP24, IP44 or IP65

are available, depending on the application. An optional

mounting plate can be supplied for surface mounted

cabling.

The strobe is available in two different versions: With or

without integrated dual-isolator module.
