Installation
3
3.0 I NSTALLATION
Before using the Liebert Web Card, the hardware and software configuration is necessary.
1. Install the Liebert IS-WEBRT3 card in the Liebert IntelliSlot
® bay on the UPS.
The bay may be protected with a plastic cover.
2. Attach an RJ-45 Ethernet cable, CAT5 or better, to the card and to your network.
3. Install Liebert DeskPro-Net Utility on your computer.
a. Insert the included DeskPro-Net Utility CD in the monitoring computer.
b. Follow the prompts to install the software.
After complete installation, DeskPro-Net Utility will appear in Start>Programs.
Figure 2 Liebert IS-WEBRT3 installation
Figure 3 Installation steps
Insert the Liebert
IS-WEBRT3 card Connect a network
cable to the Liebert
IS-WEBRT3 card
Connect the Liebert IS -WEBRT3
Card, UPS and Network
Set up the Liebert IS -WEBRT3
Card’s IP Address Using
DeskPro-Net Utility
Use a Web Browser to Connect to
Liebert IS-WEBRT3 Card
by its IP Address
Use DeskPro-Net Utility to Connect
to Liebert IS -WEBRT3 Card
Use Telnet to Configure the Liebert
IS-WEBRT3 Card UPS Settings
