A
Building Safety. Building Security.
Protective Cover WSD-FSK
The Protective Cover WSD-FSK is made of stain-
less steel and provides the Fire Brigade Key Box
FSK700-2 or FSK700-2SX with additional pro-
tection against moisture in the area of the outer
door, when rainwater hits this area from above
or at the side.
The protective cover is placed behind the blind
frame of the fi re brigade key box from above.
Dimensions W × H × D 287 Ч 267 Ч 55 (mm)
Weight 500g
Order number 249650
Order name Protective Cover for FSK700-2/2SX WSD-FSK
Specifi cations
Flush Mounting Frame with Drilling Protection EZBS700-2
The Flush Mounting Frame EZBS700-2 serves
for the installation of the Fire Brigade Key Boxes
FSK700-2 and FSK700-2SX. The integrated all-
round drilling protection allows for installation
according to the Guideline VdS 2350 in the fol-
lowing ways:
• Flush mounting: When the building is structu-
rally complete, the fl ush mounting frame is
embedded in a wall, and after completion of
the facade the fi re brigade key box is screwed
on the frame.
• Installation into a hollow stainless steel column
without concrete fi lling
• Mounting on buildings in light-weight construc-
tion, on heat-insulating facades or on any
walls that are not strong enough to provide
suffi cient protection against sabotage.
Dimensions W × H × D 275 Ч 245 Ч 160 (mm)
Weight 3.5kg
Approval VdS G106058
Order number 265818
Order name Flush Mounting Frame with Drilling Protection EZBS700-2
Specifi cations
