LST ECO1004T User Manual
Specifi cations

© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
[email protected] • WWW.LST.AT • ALL RIGHTS RESERVED
ECO1004T_DBL_LST_EN_0804.PDF • PAGE 1
A
Building Safety. Building Security.
• Addressable conventional technology
• Alarm temperature 78°C
• Individual detector addressing by
means of optional address module
• Optional connection of remote
indicator
• Function testable with Remote Test
Unit ECO1000RTU
Description
The Thermal Max Detector ECO1004T recognises a
maximum temperature of 78°C as sign of fi re. It com-
plies with Class BS and can be used up to a room
height of 6m.
Addressable conventional technology is used for alarm
transmission to the fi re detection control panel. By
means of the Address Module NG58-1, each detector
can be addressed individually.
A test activation of the detector can be carried out
using the Remote Test Unit ECO1000RTU. The detec-
tor can be attached to various detector bases and it
can be protected against theft.
Specifi cations
Operating voltage
Supply through the detector line voltage
Current consumption
typ. 75µA (quiescent)
Alarm temperature
typ. 78°C
Operating temperature
max. +60°C
Ambient temperature
-30°C to +70°C (continuous operation)
Relative humidity
5 – 95% (no condensation)
Dimensions ш Ч H
102 × 40.5 (mm)
Colour
white
Weight
70g
Approval
VdS G202042
Order number
242047
Order name
Thermal Max Detector/Conv./1000/SS ECO1004T
