Clearing jams under the fuser or fuser cover
72
Clearing jams
b
If the jammed media is not seen, grasp the tabs on the fuser cover and lift it. Grasp the jammed media, and
pull it up and out. Close the fuser cover.
If the jammed media is partially under the fuser and partially exposed from the slot behind the fuser, the operator panel
indicates a 202.xx Paper Jam.
Warning:
If jammed media is seen in the position shown in the following illustration, pull the jammed media
gently up and to the rear of the printer.
3
Close the lower door. This closes the inner door. Close the upper door.
2
1
Tab
Tab
