Description

ECO1005T_DBL_LST_EN_0804.PDF • PAGE 1

Building Safety. Building Security.

Description

The Thermal Max Detector ECO1005T recognises a

maximum temperature of 58°C as sign of ﬁ re. It com-

plies with Class A2S and can be used up to a room

height of 6m.

Addressable conventional technology is used for alarm

transmission to the ﬁ re detection control panel. By

means of the Address Module NG58-1, each detector

can be addressed individually.

A test activation of the detector can be carried out

using the Remote Test Unit ECO1000RTU. The detec-

tor can be attached to various detector bases and it

can be protected against theft.

• Addressable conventional technology
• Alarm temperature 58°C
• Individual detector addressing by

means of optional address module

• Optional connection of remote

indicator

• Function testable with Remote Test

Unit ECO1000RTU

Speciﬁ cations

Operating voltage

Supply through the detector line voltage

Current consumption

typ. 75µA (quiescent)

Alarm temperature

typ. 58°C

Operating temperature

max. +45°C

Ambient temperature

-30°C to +70°C

Relative humidity

5 – 95% (no condensation)

Dimensions ш Ч H

102 × 40.5 (mm)

Colour

white

Weight

70g

Approval

VdS G201073

Order number

242046

Order name

Thermal Max Detector/Conv./1000/SS ECO1005T
