7-5
4078-00X
Asm-
Index Part
Number
Units Description
2 -1 11A5436 1 Frame, Carrier
-2 11A5438 1 Sensor, Carrier Home
-3 11A5450 1 Motor, Carrier Transport Asm
See
“Print Quality Notice” on page
2-15 .
-4 11A5453 1 Screw, (PP)
-5 11A5453 1 Spring, Small Feed Roll Asm, (PP)
-6 11A5441 1 Feed Roll Assembly, Small
-7 11A5442 1 Mounting Bracket,
Small Feed Roll Assembly
-8 11A5443 1 Drive Train Assembly
-9 11A5444 1 Motor, Paper Feed Assembly
-10 11A5453 5 Screws, Drive Train & Paper Feed
Motor Mounting (PP)
-11 11A5453 1 Arm, Tensioner (PP)
-12 11A5449 1 Belt, Carrier
-13 11A5453 1 Spring, Large Feed Roll
Dampening (PP)
-14 11A5440 1 Feed Roll Assembly, Large
-15 11A5439 1 Frame, Mid Assembly
-16 11A5452 1 Maintenance Assembly
-18 11A5453 2 Screw, (PP)
-19 11A5453 1 Screw, (PP)
-20 11A5453 1 Screw, (PP)
-21 1367389 1 Cap and Wiper B/M
