Lochinvar Sync Condensing Boiler 1 User Manual
Page 14
14
Installation & Operation Manual
Figure 2-1 Two Pipe Sidewall Termination -
See page 22 for more details
Direct venting options - Sidewall Vent
2
General
venting
Direct venting options - Vertical Vent
Figure 2-3 Vertical Vent, Sidewall Air - See
page 18 for more details
Figure 2- 2 Two Pipe Vertical Termination -
See page 26 for more details
