A
Building Safety. Building Security.
• Addressable conventional technology
• Alarm temperature 75°C
• Individual detector addressing by
means of optional address module
• Optional connection of remote
indicator
• Extremely fl at design
• Sealed electronics
Description
The Thermal Max Detector HT-11004 recognises a ma-
ximum temperature of 75°C as sign of fi re. It complies
with Class BS and can be used up to a room height of
6m.
Addressable conventional technology is used for alarm
transmission to the fi re detection control panel. By
means of the optional Address Module NG60-1, each
detector can be addressed individually, thus allowing to
display the detector address, as well as an assigned
element text, on a suitable fi re detection control panel.
A detector fault is indicated by a yellow fl ashing of the
multicoloured status LED.
The detector can be attached to various bases and it
can be protected against theft.
Specifi cations
Operating voltage Supply through the detector line voltage
Current consumption typ. 65µA (quiescent)
Alarm temperature typ. 75°C
Operating temperature max. +65°C (continuous operation)
Ambient temperature - 40°C to +80°C (no condensation or icing)
Relative humidity 0 – 98% (no condensation)
Dimensions ш Ч H 100 × 36 (mm)
Colour white
Weight 70g
Approval VdS G204036
Order number 242033
Order name Thermal Max Detector/Conv./ORBIS/Apo HT-11004
