Vent piping materials

Use only the materials listed in Table 2A
below for vent pipe, and fittings. Failure to
comply could result in severe personal
injury, death, or substantial property
damage.

Installation must comply with local
requirements and with the National Fuel Gas
Code, ANSI Z223.1 for U.S. installations or
CSA B149.1 for Canadian installations.

Table 2A Vent Pipe and Fittings

Venting and combustion air

ƽ DANGER

The Shield water heater must be vented and
supplied with combustion and ventilation
air as described in this section. Ensure the
vent and air piping and the combustion air
supply comply with these instructions
regarding vent system, air system, and
combustion air quality. See also Section 1 of
this manual.

Inspect finished vent and air piping
thoroughly to ensure all are airtight and
comply with the instructions provided and
with all requirements of applicable codes.

Failure to provide a properly installed vent
and air system will cause severe personal
injury or death.

All vent pipes must be glued, properly
supported, and the exhaust must be pitched
a minimum of a 1/4 inch per foot back to the
water heater (to allow drainage of
condensate).

ƽ WARNING

NOTICE

ƽ WARNING

ƽ WARNING

For closet and alcove installations, CPVC
material MUST BE used in a closet/alcove
structure. Failure to follow this warning
could result in fire, personal injury, or death.

NOTICE

Requirements for installation in Canada

1.

Installations must be made with a vent pipe system
certified to ULC-S636.

IPEX is an approved vent manufacturer in Canada
supplying vent material listed to ULC-S636.

2.

The first three (3) feet of plastic vent pipe from the
appliance flue outlet must be readily accessible for visual
inspection.

3.

The components of the certified vent system must not be
interchanged with other vent systems or unlisted
pipe/fittings. For concentric vent installations, the inner
vent tube must be replaced with field supplied certified
vent material to comply with this requirement.

4.

The 3" Concentric Vent Kit available from Lochinvar (see
Section 3 – Sidewall Termination – Optional Concentric
Vent
) and the 3" Concentric Vent Kit available from IPEX
are both approved for use on the Shield Water Heater. Both
kits are listed to the ULC-S636 standard for use in Canada.

All vent pipe materials and fittings must comply with the following:

Item

Material

Standards for installation in:

United States

Canada

Vent pipe and fittings

PVC schedule 40

ANSI/ASTM D1785

CPVC and PVC venting must be

ULC-S636 Certified. IPEX is an

approved manufacturer in Canada

supplying vent material listed to

ULC-S636.

PVC-DWV

ANSI/ASTM D2665

CPVC schedule 40

ANSI/ASTM F441

Pipe cement/primer

PVC

ANSI/ASTM D2564

IPEX System 636

Cements & Primers

CPVC

ANSI/ASTM F493

NOTICE: DO NOT USE CELLULAR (FOAM) CORE PIPE

2

General venting

(continued)

Installation & Service Manual

TM

This appliance requires a special venting
system. The vent connection to the
appliance must be made with the CPVC pipe
section installed in the appliance. The field
provided vent fittings must be cemented to
the CPVC pipe section. Use only the vent
materials, primer and cement specified in
this manual to make the vent connections.
Failure to follow this warning could result in
fire, personal injury, or death.
