LANIER
– 1 /3 rd S ca le La ser 2 0 0 A R F -
INSTRU CTIO NS
© 2002 Lanier R/C Page -8
46. Install the tail w heel on the axle, then secure
w ith the sm all w heel collar and set screw . U se
som e thread lock on the screw .
47. Locate the hard points in the tail surfaces for the
tail brace w ires. Pierce the covering w ith a sharp
blade. Put a slight bend in (12) of the tail w ire
brackets, then install them in the horizontal and
vertical stabilizers as show n, w ith a bracket on
both sides of the surfaces. U se a 4-40
screw and
lock nut on each bracket.
48. Install a 2-56 clevis on the ends of the (8) 2-56
threaded rods, then install (4) rods in the m iddle
hole of the vertical braces.
49. M ark the length of the rods about ¼” past the
largest hole in the horizontal braces, then trim .
B end at 90 degrees, then insert in the hole.
Secure w ith an L connector. A djust at the clevis
end, but don’t w arp the horizontal surface.
50. Install the tail brace bracket using the rear #6
screw . A ssem ble the other (4) tail brace w ires
the sam e as the top, then secure w ith the L
connectors.
51. M ake sure each clevis gets a keeper installed.
52. Locate the (4) 4 x 20m m screw s for installation
of the cow l. (2) are round head screw s, (2) are
flat head screw s.
