Lanier LASER 200 - Manual (Page 13)

LANIER
– 1 /3 rd S ca le La ser 2 0 0 A R F -
INSTRU CTIO NS
© 2002 Lanier R/C Page -13
83. Bolt the axle through the landing gear w ith the
axles pointing out. U se thread lock on the bolt.
84. Install the tip of the axle through the pant, then a
collar, the 4”w heel and collar, then slide the
assem bly all the w ay dow n the axle. Tighten
the
w heel collar so that it does not bind the w heel
against the w heel.
85. A lign each w heel pant to the fuse so that it is
level w ith the thrust line and the rear does not
drag the ground, and keep the pair equal. D rill a
1/8” hole in the landing gear to align w ith the 4-
40 blind nut, then install the bolt and w asher.
U SE LO CK TITE O N TH IS BO LT!
86. Locate the fuel tank and rem ove all the
com ponents for assem bly. C heck the inside of
the tank for any dust or plastic shavings. B low
out if needed. If you are going to use a glow
engine, you need
to replace the stopper and line
w ith silicone parts.
87. Bend the m etal fuel tubes so the vent line fits
into the button on the top, and the pickup line is
angled tow ard the bottom just a few degrees,
then insert in the fuel stopper. Insert the clunk
on the end of the silicone fuel tubing and cut to
required length that allow it to m ove freely at the
end of the tank. Insert the nut and bolt in the
stopper, then install the stopper in the tank and
tighten.
