LANIER
– 1 /3
rd
S ca le La ser 2 0 0 A R F -
INSTRU CTIO NS
© 2002 Lanier R/C
Page -2
BUILDING INSTRUCTIO NS
Beforestarting to build this kit, w e urge you to read
through these instructions thoroughly. They contain
som e im portant building sequences as w ell as
instructions and w arnings concerning the assem bly
and use of the m odel.
BUILDING SUPPLIES NEEDED
H obby knife w / #11 blade
M edium Zap CA
30 M inute Z-poxy
W ire cutters
Pliers
D rill w ith bits: 1/32”, 1/16”, 1/8”, 5/32”, ¼”
See the list at the end of the instruction book for a
list of additional R /C equipm ent you w ill need to
com plete the 1/3
rd
Laser.
1.
Locate (10) hinge points.
2. U se the picture as a guide to find the (5) holes in
each aileron and each side of the w ing. Test fit a
hinge in each hole.
3. Put a small drop of oil on each hinge, then use 30
m inute epoxy on each hinge and hole. Press the
ailerons in place, leaving a 1/32” gap at the hinge
line, then w ipe off any excess epoxy off w ith
alcohol and a paper tow el.
4. A t the tw o locations on the w ing, rem ove the
covering from the hole to install your aileron
servo.
5. M ark the location of the aileron servo plate rails
on the inside of the plyw ood servo plate (aprox.
3/8”). Rem ove the covering from the hole for
the servo arm .
6. Position your aileron servos and the hardw ood
blocks on the plates and m ark the position.
7. G lue the blocks in place on the plates w ith 30
m inute epoxy.
8. W hen cured, replace the servo and drill 1/32”
pilot
holes
for
the
servo
screw s
included
w ith
the
