1.5 Technical Specifications
Each Logical Solutions SCS system is designed to the following specifications:
User Interface Linux command-line access via ssh or local console port
Backlit 2-line front-panel LCD display shows Network configuration
Five front-panel push buttons with UI for Network setup
Serial Interface
(Ports) [SCS160 = 16 Ports; SCS320 = 32 Ports; SCS480 = 48 Ports]
RJ45-type 8-conductor connector (DTE or DCE; software selectable)
Data rate is software selectable from 300 baud to 115KBaud
Software selectable EIA-232 parameters
256KB FIFO Buffer in RAM (per Port)
Serial Interface
(Console) 160/320/480: RJ45-type 8-conductor connector (DCE configuration)
160R/320R: Dual RJ45-type 8-conductor connector - one DTE, one DCE
Data rate is software selectable from 300 baud to 115KBaud
Software selectable EIA-232 parameters
Network interface
(Network) 160/320/480: 10/100 BaseT RJ45 8-conductor Ethernet
160R/320R: Dual 10/100 BaseT RJ45 8-conductor Ethernet
TCP/IP
CPU & Memory AMD SC520 CPU, operating at 133 MHz
256MB Compact Flash (CF) memory (non-volatile)
128MB RAM for real time use
Power Supply Universal AC Power Input, 100-240VAC 50/60 Hz, 0.5A each input
IEC-type regional cordset(s) included
Dimensions 1U, 1.75 in x 17.25 in x 14.75 in (4.5 cm x 43.8 cm x 37.5 cm)
Weight 4.5 kg (10 lbs)
Temperature Operating: 0 to 50 °C (32 to 122 °F), 30 to 90% RH, non-condensing
Storage: -20 to 70 °C (-4 to 158 °F), 10 to 90% RH, non-condensing
Relative Humidity Operating: 10% to 90% non-condensing, 40% to 60% recommended
Storage: 10% to 90% non-condensing
