Kicker SX900.4 User Manual
Page 36
36
SX .4 Series Amplifiers
Specifica
tions
Height:
2.5 inches / 6.35 centimeters
Width:
10 inches / 25.4 centimeters
Length Without EndKaps:
Subtract 5 inches (12.7 cm) from chart above
Frequency Response:
20Hz - 20kHz, +0 / -1dB
Input Sensitivity:
62.5mV - 16V
Signal-t0-Noise Ratio:
>100dB (DSP Bypass On)
High Pass Crossover Freq.:
10Hz - 16kHz in 1/12 Octave steps
High Pass Crossover Slope:
0 (off) - 36dB in 6dB steps
Low Pass Crossover Freq.:
30Hz - 20kHz in 1/12 Octave steps
Low Pass Crossover Slope:
0 (off) - 36dB in 6dB steps
KickEQ Frequency:
20Hz - 20kHz in 1/12 Octave steps
KickEQ Bandwidth (Q):
.5 to 10 in .5 steps
KickEQ Boost/Cut:
+/-18dB per Octave
Remote Bass Level Control:
Included with each amplifier
Power & Ground Terminals:
Will accept up to 1/0 Gauge wire
DSP Reaction Time / Delay:
0.7 milliseconds
(In other Words...Real Fast!)
Friend’s Reaction:
That Shizzle's Off The Hizzle
Stranger’s Reaction:
Dude...Sweet...
Specifications common
to all models.
