SX .4 Series Amplifiers
Opera
tion
Lo-Pass MENU - This menu is where you adjust the low pass
crossover for each amplifier. There are two LO-PASS menus,
one for AMP 1 and one for AMP 2. This allows each amplifier to
have its own individual LO-PASS
setting.
Use the
UP
and
DOWN
keys to
scroll through AMP-1 and AMP-2 and
press the
ENT
key to select the
amplifier you want to adjust.
Your options for each amplifier are
frequency and slop[e. Use the
UP
and
DOWN
keys to choose one and
press the
ENT
key to select it.
FREQUENCY selects the crossover point and can be set at any
1/12th octave frequency from 30 Hz to 20 kHz.
(
30 Hz to 20325 Hz )
Use the
UP
and
DOWN
keys to
select your frequency. Press the
ESC
to return to the selected
amplifier’s LO-PASS menu.
SLOPE selects the rolloff of the crossover and can be set
from oFF to 36 dB in 6 dB steps.
Use the
UP
and
DOWN
keys to
select your slope. Press the
ESC
to
return to the selected amplifier’s
LO-PASS menu.
When you are done adjusting the
selected amplifier’s LO-PASS crossover
press the
ESC
key to return to the
LO-PASS menu AMP-1 / AMP-2 options
to select the other amplifier.
If done adjusting the LO-PASS
crossover, press the
ESC
key again
to return to the MAIN menu
NOTE...
While adjusting the LO-PASS crossover you will notice the
LPF indicator on the ISIS VFD display is lit. This indicates
you are in the LO-PASS crossover menu.
The AMP1 or AMP 2 indicator will light up to indicate which
amplifier you are currently adjusting.
The KICKER SX amplifier monitors and prevents any low pass
crossover point from being any closer than 1/3 octave from the
high pass crossover point. If you cannot set the low pass
crossover where you want then check the
HPF indicator and see
if it is flashing. If it is then you need to go to the HI-PASS menu
and raise the high pass crossover point.
This is done as a safety precaution to prevent a notch filter
condition.
