12
SX .4 Series Amplifiers
I
NST
ALLA
TION
USING THE REMOTE BASS LEVEL CONTROL & BLAST
You can use the Remote Bass Level Control to control the
output of your amplifier from the front of the car.
Mount the controller by simply screwing the metal bracket to
the chosen location and then slide the housing onto the bracket
until it snaps into place.
Route the cable from the controller to the BLAST input jack on
the amplifier chassis. That’s it.
If you wish to control more than one amplifier with your remote,
you will simply need to use a RJ45 cable (not supplied but
available at any Radio Shack, computer store or electronics
center) to connect the BLAST output jack of the first amp to the
BLAST input jack of the next amplifier.
On a KICKER SX.4 series amplifier you can control AMP 1,
AMP 2 or both of them using the Remote Bass Level Controller.
There is a setting you must adjust in the DSP to ‘tell’ the amplifier
which one you want to control. See the Operation section of this
manual for instructions on how to adjust this setting.
SOURCE UNIT
To Next Amplifier or Processor
AMP 1 RCA CABLE (FRONT)
AMP 2 RCA CABLE (REAR)
BACK VIEW
SIDE VIEW
Mounting Surface
SUPPLIED
CABLE
OPTIONAL
RJ45 CABLE
OPTIONAL
RJ45 CABLE
