English 75
Audio section
Preout Level/Load
KDV-MP6333 : 2500 mV/10 kΩ (CD/CD-CH)
KDV-MP6433 : 4000 mV/10 kΩ (CD/CD-CH)
Video Out Level/Load
: 1 Vp-p /75 Ω
Preout Impedance
: ≤ 600 Ω
Speaker Impedance
: 4 – 8 Ω
Maximum Power
: 50 W × 4
Full Bandwidth Power (at less than 1% THD)
: 22 W × 4
Tone action
Bass : 100 Hz ± 8 dB
Middle : 1 kHz ± 8 dB
Treble : 10 kHz ± 8 dB
AUX input (KDV-MP6333 only)
Frequency Response (±1 dB)
: 20 Hz – 20 kHz
Input Maximum Voltage
: 1200 mV
Input Impedance
: 100 kΩ
General
Operating voltage
: 14.4 V (11 – 16 V allowable)
Current Consumption
: 10 A
Installation Size (W × H × D)
: 182 Ч 53 Ч 155 mm
Weight
: 1.4 kg
