KTM SUPERENDURO R 950 - Manual (Page 13)

950 SUPERENDURO R AUS/UK 2007
FIG PART NUMBER DESCRIPTION QTY
46* 60103088000 PLUG ZK 8/5 06 4
50 59003040250 FOOT PED L/S SILVER 02 1
51 59003041250 FOOT PED R/S SILVER 02 1
56 54803044000 BOLT FOR FOOT PED 03 2
57 54603041000 FOOTREST SPRING L/S & R/S 2
58 0125100003 WASHER DIN0125-A10,5 2
59 0094032253 PIN DIN0094-3,2X25 STEEL 2
61 63003094000 FRAME PROTECTION SET 06 1
62 44011076305 CABLE TIE 300/4,8MM BLACK 2
63 0015060163 HH COLLAR SCREW M 6X16 WS=8 2
64 50308052000 BUSH FOR SPOILER 6X11X16X5 MM 2
65 0015060353 HH COLLAR SCREW M 6X35 WS=8 1
66 0015060303 HH COLLAR SCREW M 6X30 WS=8 1
076300300 / C076300300 * NEW PART X AS REQUIRED
11
FRAME, SUB FRAME
