Loading Paper (continued)
8-8 Maintenance & Supplies
Maintenance & Supplies
Loading Tabbed Sheets in Multi-Sheet Bypass Tray
Load offset tabbed sheets so that the tab extensions are on the right at the rear (not front)
of the tray. The top sheet is designated face up as the first tab of the finished set.
Subsequent offset tab sheets follow in sequence. The tab extension width should be 0.5"
(12.5 mm) or less.
When loading tabbed sheets in the Multi-sheet bypass tray, be sure to specify the paper
type as Tab paper on the Paper Type/Size Setting Screen; otherwise mishandled paper
may occur.
Section 1
Introduction
Section 1
Introduction
Section 1
Introduction
Section 1
Introduction
Section 1
Introduction
Section 1
Introduction
Section 1
Introduction
Section 1
Introduction
3rd TABS
2nd TABS
1st TABS
3 FINISHED SETS
ONE FINISHED SET
Example: 9 Tabbed sheets loaded in position for 3 finished sets.
Example: 3 Tabbed sheets loaded in position for one finished set.
3rd TAB
2nd TAB
1st TAB
Printed
side
Printed
side
1st TAB 2nd TAB
3rd TAB
2nd TAB
3rd TAB
1st TAB
Rear
Front
Rear
Front
