Assembly

38

Step 24

Connect Long Lat Bar (43) to the Lat Cable (110) using two Gear Hooks (87) and Short Chain
(88).
Connect Ab Strap (60) or Lat Strap (61) to Low Row Cable (111) using one Gear Hook (87).
Connect Short Lat Bar (44) or Ankle Strap (62) to Low Row Cable (111) using two Gear
Hooks (87) and Long Chain (116).

Figure 24
