23
User Guide
E
SCC-100BP/101BP/130BP/131BP
Item
Contents
Product Type
CCTV Camera
Broadcasting
PAL STANDARD SYSTEM
System
CCD
1/3” IT type S-HAD CCD
No. of Pixel
100BP/130BP : 500(H) x 582(V)
101BP/131BP : 752(H) x 582(V)
Scanning Type
625 Line, 2:1 Interlace
Frequency
INTERNAL : 15,625 H
Z
(H)
50 H
Z
(V)
LINE LOCK :15,625 H
Z
(H)
50 H
Z
(V)
Sync Type
INTERNAL
LINE LOCK(
When AC power source is used)
Resolution
100BP/130BP : 330TV Lines
131BP/101BP: 520TV Lines
S/N Ratio
50dB (AGC OFF)
Min. Object
100BP/130BP : 0.15 Lux (F1.2)
Illumination
131BP/101BP : 0.3 Lux (F1.2)
User Guide
22
ALC /ELC
ALC
DC IRIS LENS
VIDEO LENS
ELC
Electronic SHUTTER IRIS function
1/60 to 1/120,000 sec
Color Temperature ATW/AWC Mode
BLC
ON(Back Light Compensation)
AGC
ON
Video Output
COMPOSITE VIDEO OUT
1V p_p 75
/BNC
Power Source
AC24V 10%(60Hz 0.3Hz)
DC12V -5% ~ +10%
Power Consumption About 3 Watts
Operating
-10 ~+50
Temperature
Operating
~90%
Humidity
Size
65(W) x 52(H) x 133(L)mm
(BNC included)
Weight
450g
