Power Connection Terminal
Terminal to be connected to the power (adapter) cable
Connect it to AC 24V or DC 12V.
Power Indication LED
While the power is properly supplied to the camera, the
LED is turned on.
,
INC/DEC Switch
The LINELOCK mode is useful for controlling Vertical
Synchronous Phase.
17
User Guide
E
User Guide
16
AC24V/DC12V Power Input Camera
• Rear Panel
AC230V Power Input Camera
