21
User Guide
E
5. Product Specifications
SCC-130B/131B
Item Contents
Product Type CCTV Camera
Broadcasting NTSC STANDARD SYSTEM
System
CCD 1/3” IT type S-HAD CCD
No. of Pixel 130B : 510(H) x 492(V)
131B : 768(H) x 494(V)
Scanning Type 525 Line, 2:1 Interlace
Frequency INTERNAL : 15,734 H Z (H)
59,94 H Z (V)
LINE LOCK :15,750 H Z (H)
60 H Z (V)
Sync Type INTERNAL
LINE LOCK( When AC24V power source is used)
Resolution 130B : 330TV Lines
131B: 520TV Lines
S/N Ratio 50dB (AGC OFF)
Min. Object 130B : 0.15 Lux (F1.2)
Illumination 131B : 0.3 Lux (F1.2)
DC Iris Level Control
When the ALC Lens Selection Switch is set to DC, adjust
this Iris Level Control using an adjustment rod such as a
screwdriver.
Video Output Terminal
This is a terminal to be connected to the Input Terminal
of the monitor. Through this terminal, the video signals
are outputted.
User Guide
20
