NAMES OF PARTS

For information on specific parts, refer to the page numbers shown in parenthesis.

Body

Exposure
mode dial (36-43)

Data Panel

Rear control dial

Shutter-release
button

Front
control dial

Built-in flash* (22-23)

Exposure-
compensation
dial lock (50)

Exposure-
compensation
dial (50)

Flash
compensation
dial (67)

Accessory shoe

Drive-mode lever (54)

AF Illuminator /
Self-timer lamp
(34, 56)

Grip sensor (76)

Depth-of-field
preview button (77)

Lens mount (12)

Mirror*

AF mode dial (28)

Focus-mode switch (33)

Lens release (12)

Mounting
index

Lens contacts*

Battery-chamber lock (10)

Battery-chamber door (10)

Vertical control grip contacts

(104)

Tripod socket

Diopter
adjustment dial (9)

Viewfinder*

Eyepiece cup

Eyepiece shutter
lever (79)

Main switch

Eyepiece
sensor* (76)

Film window

Eye-start switch (76)

Flash-mode switch

AF button (32)

AE-lock button (48)

Data-panel
illuminator (82)

Metering-mode
switch (45-47)

PC terminal
(81)

Back-cover
release (15)

Remote-control
terminal (80)

Strap eyelet

* Do not touch

Flash-
compensation
dial lever (67)

Dirve mode
dial (54-61)
