16
Preparations
DVT-6200 (EN/K,E,X)
The keys on the remote control unit with the same names as on the
main unit have the same function as the keys on the main unit.
1 REPEAT key t
A-B (Repeat) key t
RANDOM key r
2 Numeric keys ‡
3 PGM (Program) key u
4 CLEAR key i
5 ANGLE key r
RDS DISP. (for Europe only) key
°
PTY (for Europe only) key ·
6 TOP MENU/INTRO SCAN key
‚y
7 Cursor Up (5), Down (∞), Left
( 2) and Right (3) keys )
ENTER/PRESET key )
8 RETURN key (
9 P.CALL /4,¢ (Skip) keys
flq
TUNING/ 1,¡ (Search) keys
flq
0 8 (pause) key ‚
3 (play) key ‚
! SUBTITLE key e
AUDIO key e
SLOW key w
STEP key q
Loading batteries
2 Insert batteries. 3 Close the cover. 1 Remove the cover.
÷ Insert two R6 (“AA”-size) batteries fol-
lowing the polarity indications.
Operation
Insert the power plug into a power outlet, press the POWER
switch of the main unit to ON, then press the POWER key
on the remote control.
÷ When pressing more than one remote control keys successively,
press the keys securely by leaving an interval of 1 second or more
between pressing of keys.
Operating range (approx.)
Remote sensor
1. The provided batteries are intended for use in operation checking, and their service life may be short.
2. When the remote controllable distance becomes short, replace both of the batteries with new ones.
3. If direct sunlight or the light of a high- frequency fluorescent lamp (inverter type, etc.) is incident to the remote sensor, malfunction
may occur. In such a case, change the installation position to avoid malfunction.
Model : RC-R0310E (for Europe)
RC-R0310 (for other countries)
Infrared ray system
Operation of remote control unit
Notes Notes Notes
1
2
3
5
7
8
9
0
!
@
#
$ ™
¡
)
(
*
&
^
%
4
6
@ Speaker select keys ¤
FRONT key
CENTER key
REAR key
SW (Subwoofer) key
# LISTEN MODE key ª
ACTIVE EQ./SET UP key º
$ MUTE key ›
% POWER key *
^ INPUT SELECTOR keys ›
DVD/CD key
TUNER/BAND key
VCR key
CABLE/SAT. (Satellite) key
& BOOK MARK key y
* MENU/P.B.C. key )
( ON SCREEN key w
) 7 (stop) /AUTO/MONO key
fl‚
¡ TRIM
Up ( 5), Down (∞) keys ª
™ VOLUME
Up ( 5), Down (∞) keys ›
30º
30º
6m
1
2
