42 | English
Menu system
Function of the DPX701
G-Analyzer Stop Watch
The control of stop watch can be started by G-
Analyzer function.
• Do not use G-Analyzer stop watch on the Public roads.
1 Select G-Analyzer Stop Watch mode
Push the Control knob towards [FM] or [AM].
Select the "Stop Watch" display.
2 Enter G-Analyzer Stop Watch mode
Press the Control knob for at least 1 second.
"Stop" is displayed.
3 Enter Counter Ready mode
Press the Control knob.
"Ready" is displayed.
4 Start Count
When G in the vertical direction is detected
during the travel, the count automatically starts.
"Running" is displayed.
• You can also start the counter by pressing the Control
knob.
5 Stop Count
Press the Control knob.
"Stop" is displayed.
• The control will start again when you accelerate or
press the Control knob.
Do the operation after step3.
When you Reset the Count
(While "Stop" is displayed)
Press the Control knob for at least 2 seconds.
• You can reset of count when the count is stopped.
6 Exit G-Analyzer Stop Watch mode
Press the [MENU] button.
• When "Running" is displayed (counted), the count is
continued even though G-Analyzer Stop Watch mode
is finished. If you want to stop the count, enter the
menu mode then press the control knob.
• When Power off (ex; ACC OFF) while counting, the
value of 1 second or less will be "00".
Other than Standby mode/
When the Dual Zone System is ON
Dual Zone System Setting
Setting the Front channel and Rear channel
sound in the Dual Zone System.
Display Setting
"Zone2 : Rear"/
"ZONE2 R" Sub source (Auxiliary input source) is to be rear
channel.
"Zone2 : Front"/
"ZONE2 F" Sub source (Auxiliary input source) is to be front
channel.
Function of the DPX701
Other than Standby mode
B.M.S. (Bass Management System)
Adjust the bass boost level of the external
amplifier using the main unit.
Display Setting
"AMP Bass : Flat" Bass boost level is flat.
"AMP Bass : +6" Bass boost level is low (+6dB).
"AMP Bass : +12" Bass boost level is mid (+12dB).
"AMP Bass : +18" Bass boost level is high (+18dB).
• Refer to the catalog or instruction manual for power
amplifiers that can be controlled from this unit.
• For amplifiers, there are the models you can set from
Flat to +18 dB, and the models you can set from Flat
to +12 dB.
When an amplifier that can only be set to +12 is
connected to the unit, "AMP Bass : +18" will not work
correctly even if it is selected.
