84 English
Sound Effects Menu
Zone Control
You can set the front and rear audio source.
Displaying the Zone Control
screen
Zone Control screen
Zone Control
1 Adjusts the volume.
2 Returns to the Control screen of the previous
source.
3 Calls the Setup Menu. (see page 49)
4 Calls the Sound Effects Menu.
5 Turns the Zone Function (that sets different source
sounds for front and rear speakers) On or Off.
When turned On,
and are shown.
6 Adjust the front and rear audio balance.
(This button appears when the Zone function is On.)
When the Zone function is turned On, this button
appears on the all source control screen.
7 Sets the front and rear audio source separately.
(This button appears when the Zone function is On.)
When the rear speaker sound is switched, the
audio source that is output at the AV OUTPUT
terminal is also switched to the same source.
However, if you have set the "Area" to "Reverse",
the audio source that is output at the AV OUTPUT
terminal is switched depending on the front sound
source.
8 Switches the front and rear audio sources.
(This button appears when the Zone function is On.)
Use "Reverse" to change over the front and rear
audio sources.
Rear Front
Reverse
DVD
Rear
Rear Fron
Area
1
1
1
1
4
5
6 6
7
8
7
3
2
