Parametric Equalizer
You can Manually set the equalizer curve by
adjusting the center frequency, gain and Q
value.
1 Adjusts the volume.
2345 Select a band to be adjusted.
6 Sets a frequency.
7 Sets a gain level.
8 Sets a Q value.
9 Store the present equalizer curve in memory, or
calls it from memory.
0 Exits the Parametric Equalizer setup and returns
to the Equalizer screen.
—
You can adjust the following frequency bands.
2 60, 80, 100, 120, 160, 200, 250 Hz
3 315, 400, 500, 630, 800, 1k Hz
4 1.25k, 1.6k, 2k, 2.5k, 3.15k, 4k Hz
5 5k, 6.3k, 8k, 10k, 12.5k, 16k Hz
Set a gain 4
Set a center frequency 3
Band4 Band1
Select a frequency band you wish to adjust 2
P-EQ
Display the Parametric Equalizer screen 1
To store the equalizer curve in memory:
—
Continue to touch to more than 2
seconds.
To call the equalizer curve from memory:
—
Touch to of the equalizer curve you
wish to call from memory.
When you call an equalizer curve, its type is shown
as "USER#".
Return
Close the Parametric Equalizer screen 6
P3 P1
P3 P1
P3 P1
P3 P1
Store or call the equalizer curve into/from
memory
Q+ Q-
Set a Q value 5
English 81
Q-
P3 P2 P1
Q+
Return
Frq 80Hz
Gain
+12dB
Q
1.0
Band1
7
7
8
1
1
1
1
3 4 5 2
6
9
6
10
