-36-

4. VLAN Lookup

Syntax:

VLAN Lookup

Description:

Lookup VLAN entry and show port list.

: VLAN ID list.

5. VLAN EgressTagging

Syntax:

VLAN EgressTagging [] [enable|disable]

Description:

Set or show the VLAN Egress Tagging mode for the port. The enabled ports

will strip the VLAN tag from received frames and insert the tag in trans-

mitted frames (except PVID). The disabled ports will not strip the tag

from received frames or insert the tag in transmitted frames.

[]: Port list (default: All ports).

[enable|disable]: Enable/disable VLAN egress tagging (default: Show

awareness).

6. VLAN PVID

Syntax:

VLAN PVID [] [|none]

Description:

Set or show the port VLAN ID. Untagged frames received on the port will

be classified to this VLAN ID. Frames classified to this VLAN ID will be

sent untagged on the port.

[]: Port list (default: All ports).

[|none]: Port VLAN ID, 1-4094 (default: Show PVID).

The none option can be used for trunk links.

7. VLAN Frame Type

Syntax:

VLAN Frame Type [] [all|tagged]

Description:

Set or show the accepted frame type for the port.

[]: Port list (default: All ports).

[all|tagged]: Accept all or only tagged (default: Show frame type).

7.7.6 Aggregation/trunking Commands

Commands at Aggr level:

Aggr Configuration

Aggr Add

Aggr Delete

Aggr Lookup

Aggr Mode [smac|dmac|xor]

1. Aggregation Configuration

Syntax:
