-26-
6. Product Specifications
Standard IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX
IEEE802.3x full-duplex operation and flow control
IEEE802.3ab 1000BASE-T
IEEE802.1Q VLAN interoperability
Interface 24 * 10/100/1000Mbps auto MDI/MDI-X RJ-45 switching ports
1 * RS-232 Console port
Cable Connections RJ-45 (10BASE-T): Category 3,4,5 UTP/STP
RJ-45 (100BASE-TX): Category 5 UTP/STP
RJ-45 (1000BASE-T): Category 5,5e or enhanced UTP/STP
Network Data Rate 10/100/1000Mbps Auto-negotiation
Transmission Mode 10/100Mbps Full-duplex, Half-duplex
1000Mbps Full-duplex
LED indications System Power
RJ-45 Port 10/100M; 1000M link/act
Memory 8K MAC entries
400K Buffer Memory
Emission FCC Class A, CE
Operating Temperature 0 0 ~ 50 0 C (32 0 ~ 122 0 F)
Operating Humidity 10% - 90%
Power Supply Internal power supply 5V 10A 100-240V/ 50-60H
Power Consumption 43W max.
