Kerio Tech KERIO WINROUTE FIREWALL 6 User Manual
Page 81
7.3 Definition of Custom Traffic Rules
81
Figure 7.11
Traffic rule — VPN clients / VPN
tunnel in the source/destination address definition
tunnel The All option covers all networks connected by all VPN tunnels defined
which are active at the particular moment.
For detailed information on the proprietary VPN solution integrated in WinRoute, refer
to chapter
•
Users — users or groups that can be chosen in a special dialog
Figure 7.12
Traffic rule — users and groups in the source/destination address definition
The Authenticated users option makes the rule valid for all users authenticated to the
firewall (see chapter
). Use the User(s) from domain option to add users/groups
from mapped Active Directory domains or from the local user database (for details,
refer to chapter
).
Hint
Users/groups from various domains can be added to a rule at a moment. Select a do-
main, add users/groups, choose another domain and repeat this process until all de-
manded users/groups are added.
In traffic rules, user are represented by IP address of the host they are connected
(authenticated) from. For detailed description on user authentication, refer to chap-
ter
