Chapter 19 Status Information
242
For each item either a color or the Default option can be chosen. Default colors are set in the
operating system (the common setting for default colors is black font and white background).
Font Color
• Active connections — connections with currently active data traffic
• Inactive connections — TCP connections which have been closed but 2 minutes
after they were killed they are still kept active — to avoid repeated packet mis-
handling)
Background Color
• Local connections — connections where an IP address of the host with WinRoute
is either source or destination
• Inbound connections — connections from the Internet to the local network (al-
lowed by firewall)
• Outbound connections — connections from the local network to the Internet
Note: Incoming and outgoing connections are distinguished by detection of direction of
IP addresses — “out” (SNAT) or “in” (DNAT). For details, refer to chapter 7 .
19.3 List of connected VPN clients
In Status → VPN clients, you can see an overview of VPN clients currently connected to the
WinRoute’s VPN server.
Figure 19.10 List of connected VPN clients
The information provided is as follows:
• Username used for authentication to the firewall. VPN traffic is reflected in statistics
of this user.
• The operating system on which the user have the Kerio VPN Client installed.
• DNS name of the host which the user connects from. If WinRoute cannot resolve the
corresponding hostname from the DNS, its (public) IP address is displayed instead.
• IP address assigned to the client by the VPN server. This IP address “represents” the
client in the local network.
• Session duration.
• Kerio VPN Client version, including build number.
The following columns are hidden in the default settings of the VPN clients window (for details
on showing and hiding columns, see chapter 3.2 ):
