Scag Power Equipment STT - Manual (Page 73)

69
Section 8
1 483055 Wire Harness, STT Air Cooled
2 48298 Fuse, 20 AMP
3 48017-02 Key & Ring Assembly
4 48017-04 Nut, Hex 5/8-32
5 48017-03 Lockwasher, 5/8" Internal
6 461916 Instrument Panel, Top w/Decals
7 48798 Key Switch
8 483162 Switch, PTO
9 483013 Relay
10 04031-01 Lockwasher, #10 External Tooth
11 04020-01 Nut, Hex #10-32
12 481755 Ammeter
13 451879 Base, Instrument Panel
14 04030-02 Lockwasher, 1/4"
15 04001-01 Bolt, Hex Head 1/4-20 x 3/4"
16 04110-01 U-Nut, 1/4-20
17 481544 Throttle And Choke Controls (Kohler)
481662 Throttle And Choke Controls (35BVAC Briggs & Stratton)
18 04010-01 Screw, Phillips Washer Head #10-32 x 1/2"
19 481638 Switch, Interlock-Seat
20 04001-44 Bolt, Hex Head 1/4-20 x 1/2"
21 48029-22 Cable, Battery - Red
22 04020-02 Nut, Hex 1/4-20
23 48029-11 Cable, Battery - Black
24 48030-09 Clamp, Cable 1/2" ID.
25 48136-05 Clamp, Cable 3/4" ID.
26 483029 Electronic Module
27 04002-12 Bolt, Hex Head M8-1.25 x 20
28 04031-03 Lockwasher, 5/16" External Tooth
29 48430 Fuse Holder w/Fuse and Connector
482588 Clip, Fuse Holder
30 482849 Wire Harness Adapter 35BVAC (Briggs & Stratton Only)
Ref. Part
No.
No. Description
ELECTRICAL SYSTEM (KOHLER & 35BVAC)
