Scag Power Equipment STT - Manual (Page 45)

41
Section 8
1 461859 Cutter Deck Velocity Plus x
461863 Cutter Deck Velocity Plus x
2 04003-40 Bolt, Carriage 7/16-14 x 1-1/4" x x
3 04019-04 Nut, Hex Serrated Flange 3/8-16 x x
4 481625-01 Wing nut, 3/8-16 x x
5 481632 Anti-Scalp Wheel x x
6 04003-26 Bolt, Carriage 3/8-16 x 4" x x
7 422478 Anti-Scalp Wheel Bracket x x
8 04017-27 Bolt, Hex Serrated Flange 3/8-16 x 1" x x
9 04043-06 Flatwasher, 5/8" Hardened x x
10 04021-05 Locknut, 3/8-16 Center Lock x x
11 461845 Discharge Chute x
461846 Discharge Chute x
12 04001-11 Bolt, Hex Head 5/16-18 x 1-3/4" - Front x x
04001-12 Bolt, Hex Head 5/16-18 x 1-1/2” - Rear
13 04021-22 Nut, Hex Elastic Stop 5/16-18 Grade 8 x x
14 04020-09 Nut, 5/8-11 UNC x x
15 451240 Push Arm Shaft x x
16 04001-41 Bolt, Hex Head 5/8-11 x 9-1/2" x x
17 04003-12 Bolt, Carriage 5/16-18 x 3/4" x x
18 04001-108 Bolt, Hex Head 5/16-18 x 4-1/2" x x
19 04063-08 Key, 1/4 x 1/4 x 2" x x
20 04063-01 Key, 1/4 x 1/4 x 1-1/4" x x
21 04043-04 Flatwasher,3/8-.39 x .938 x .105 HD x x
22 04001-176 Bolt, Hex Head 5/16-18 x 1-3/4" x x
23 04019-03 Nut, Hex Serrated Flange 5/16-18 x x
24 04001-172 Bolt, Hex Head 1/4-20 x 1” Grade 8 x x
25 48100-15 Bushing, .376 I.D. Oilite x x
26 04030-03 Lockwasher, 5/16" x x
27 04040-15 Flatwasher, 5/16" (.375 x .875 x .083) x x
28 04041-07 Flatwasher, 3/8" (.391 x .938 x .105) x x
29 04021-09 Nut, Hex Elastic Stop 3/8-16 x x
30 04001-62 Bolt, Hex Head 3/8-16 x 3-1/4" x x
31 04001-54 Bolt, Hex Head 3/8-16 x 3" x x
32 04001-20 Bolt, Hex Head 3/8-16 x 1-1/2" x x
33 04001-136 Bolt, Hex Head 3/8-16 x 1-1/2" Grade 8 x x
34 461663 Spindle Assembly x x
35 43589 Spindle Shaft x x
36 481024 Seal, Top x x
37 481022 Bearing Assembly x x
38 43644 Spindle Housing x x
39 43312 Spacer, Outside x x
40 43296 Spacer, Inside x x
41 481025 Seal, Bottom x x
42 43297 Spindle Bushing, Bottom x x
43 481035 Nut, Special 1 - 1/16-18 x x
44 48114-04 Grease Fitting x x
45 48677 Relief Fitting, Tapered Spindle x x
46 483378 Spring, Discharge Chute x x
47 482295 Wheel, Anti-Scalp x x
48 482878 Cutter Blade, 18" x
482879 Cutter Blade, 21" x
482881 Cutter Blade, 21” (BV, BVAC Only) x
49 482486 Gearbox Assembly, Deck Drive x x
50 482281 Belt, Cutter Deck Drive x
481558 Belt, Cutter Deck Drive x
51 45944 Roller Shaft x x
52 48926 Tapered Hub, 1-1/8" Bore x x
53 48141 Tapered Hub, 1" Bore x x
54 461842 Idler Arm, Cutter Deck x x
55 48224 Bearings, Ball x x
56 483215 Pulley, Idler x x
57 461929 Lever Assembly, Deck Level (Incl. 77) x x
58 482744 Pulley, 5.75 O.D. (52’) x
482745 Pulley, 6.35 O.D. (61”) x
59 422426 Mounting Plate, Gearbox x x
60 422412 Belt, Cover x
424325 Belt, Cover x
61 461516 Pusharm (incl. items 44, 63 & 64) x x
62 43590 Spacer, Spindle Bottom x x
63 04020-16 Nut, Hex Head 5/8-18 UNF x x
64 48763 Rod End, 5/8" Male RH Thread x x
65 04001-79 Bolt, Hex Head 5/8-11 x 4-1/2" x x
66 481597 Spring, Cutter Deck x x
67 482747 Pulley, 6.95 O.D. x
482746 Pulley, 6.75 O.D. x
68 04110-03 U-Nut, 3/8-16 x x
69 04021-13 Nut, Hex Elastic Stop 5/8-11 x x
70 424208 Discharge Baffle 52V x
71 424209 Discharge Baffle 61V x
72 43681 Pivot, Idler - Short x x
73 424174 Baffle, Custom Cut 52V x
424164 Baffle, Custom Cut 61V x
74 04003-23 Bolt, Carriage 3/8-16 x 1” x x
75 04040-11 Flatwasher, 7/16-.500 x 1.25 x .083 x x
76 04021-11 Nut, Elastic Stop 7/16-14 x x
77 483167 Bolt, Deck Adjust x x
78 04003-12 Bolt, Carraige 5/16-18 x 3/4” x x
79 04040-04 Flatwasher, 5/16” x x
80 04021-04 Nut, Center Lock 5/16-18 x x
81 483176 Wear Pad x x
82 48038 Wheel, Anti-Scalp x x
52V & 61V CUTTER DECKS
Ref. Part
No. No.
Description 52 61
Ref. Part
No. No.
Description 52 61
