Section 8
STT ROLL-OVER PROTECTION SYSTEM - WITHOUT
SUSPENSION SEAT
1 9514 STT, ROPS Acessory (incl. all items below)
2 04001-82 Bolt, Hex Head 1/2-13 x 4-1/2”
3 04021-19 Nut, Center Lock 1/2-13
4 04040-13 Flatwasher, 1/2-.562 x 1.375 x .109
5 483 594 Retractable Seat Belt
6 04001-145 Bolt, Hex Head 1/2-13 x 3-1/2”
7 04021-19 Nut, Center Lock 1/2-13
8 424407 Bracket, Stop
9 483262 Pin
10 481625-03 Thumb Screw, 5/16-18 NC x 3-4”
11 04062-06 Hair Pin, Cotter
12 483265 Clamp
13 04001-178 Bolt, Hex Head 7/16-20 x 1”
14 Spacer
15 04040-11 Flatwasher, 7/16-.500 x 1.25 x .083
16 43606 Sleeve, Seat Base Mounting
17 04041-07 Flatwasher, 3/8-.391 x .938 x .105
18 04001-45 Bolt, Hex Head 3/8-16 x 2”
19 04019-03 Nut, Serrated Flange 5/16-18
20 04001-09 Bolt, Hex Head 5/16-18 x 1”
21 04021-09 Nut, Elastic Stop 3/8-16
22 461968 Bracket, Seat Hold Down w/Decal
23 424193 Spacer, Seat Hold Down
Ref. Part
No. No.
Description
