47
Section 8
Ref. Part
No.
No. Description
SHEET METAL COMPONENTS
1 451481 Fender Weldment, RH
2 04001-09 Bolt, Hex Head, 5/16-18 x 1, Zinc
3 43606 Spacer
4 04041-07 Flatwasher, 3/8-.391 x .938 x .105
5 461967 Seat Plate Weldment
6 483384 Seat Assembly w/armrest and seat belt
7 04001-45 Bolt, Hex Head 3/8-16 x 2.0”
8 04021-09 Nut, Elastic Stop 3/8-16
9 * Battery (not avail. through Scag)
10 48903 Pad, Battery Cover
11 421274 Cover, Battery
12 04003-12 Bolt, Carriage 5/16-18 x 3/4"
13 423308 Plate, Battery Box
14 04029-01 Wing Nut, 1/4-20 x 3/4"
15 04019-03 Nut, Hex Serrated Flange 5/16-18
16 04003-01 Bolt, Carriage 1/4-20 x 6"
17 48661 Rubber Pad
18 43584 Spacer, Caster Wheel
19 04003-04 Bolt, Carriage 5/16-18 x 1"
20 482622 Seal
21 04021-09 Lock Nut, 3/8-16, Elast. Stop
22 461991 Main Frame
23 04019-04 Nut, Hex Serrated Flange 3/8-16
24 04017-27 Screw, Hex Serrated Flange 3/8-16 x 1”
25 451480 Fender Weldment, LH
26 423489 Foot Plate
27 04021-09 Nut, Hex Elastic Stop 3/8-16
28 04001-19 Bolt, Hex Head 3/8-16 x 1”
29 04001-125 Bolt, Hex Head 5/8-11 x 4”
30 04021-13 Nut, Hex Elastic Stop 5/8-11
31 481559 Cap, Grease
32 04021-20 Nut, Hex Elastic Stop 1.0-14
33 481657 Bearing W/Race
34 482028-01 Plug, 1/4-28 THD Form
35 451450 Extention Weldment, Caster 52A
451825 Extention Weldment, Caster 61A (LH)
451451 Extention Weldment, Caster 61A (RH)
451452 Extention Weldment, Caster 72A (LH)
451453 Extention Weldment, Caster 72A (RH)
36 481025 Seal, 2.00 OD. x 1.625 Bore
37 04021-07 Nut, Hex Elastic Stop 1/2-13
38 45934 Yoke Weldment, Caster (52A)
451416 Yoke Weldment, Caster (61A & 72A)
39 04001-134 Bolt, Hex Head 1/2-13 x 7-1/2" (52A)
04001-167 Bolt, Hex Head 1/2-13 x 9-1/2” (61A & 72A)
40 43581 Sleeve, Caster Wheel (52A)
43583 Sleeve, Caster Wheel (61A, 72A)
41 9277 Wheel Assy, 52A (Inc.items 20, 54, 55)
9278 Wheel Assy, 61A, 72A (Inc. 20, 54, 55)
42 04001-01 Bolt, Hex Head 1/4-20 x 3/4”
43 04001-01 Bolt, Hex Head 1/4-20 x 3/4”
44 423674 Mounting Bracket, STT Cup Holder
Ref. Part
No.
No. Description
45 482943 Lumbar Kit
482948 Knob Kit
46 48566 Cable, Seat Stop
47 482940 Back Cushion Kit
48 9240 Cup Holder Assembly
49 482502 Seat Adjustment, Track Set
50 461907 Caster Wheel Assy (Inc. 31 thru 43)
52V
461908 Caster Wheel Assy (Inc. 31 thru 43)
61V (LH)
461909 Caster Wheel Assy (Inc. 31 thru 43)
61V (RH)
461910 Caster Wheel Assy (Inc. 31 thru 43)
72A (LH)
461911 Caster Wheel Assy (Inc. 31 thru 43)
72A (RH)
51 482614 Back Cushion Cover
52 482615 Seat Cushion Cover
53 482618 Arm Rest, Right Hand
482617 Arm Rest, Left Hand
482616 Arm Rest Cover
54 482621 Bearing w/ Race
55 48114-10 Grease Fitting
56 481389 Spring, Seat
57 43462 Pin Retainer, Spring
58 04060-01 Roll Pin, Spring 5/32 x 3/4”
59 483428 Suspension Seat Assembly w/seat belt
60 482950 Armrest Only
482945 Armrest Assembly Kit, LH
482946 Armrest Assembly Kit, RH
61 482941 Seat Cushion Kit
Seat Drain Kit (Included with Seat Cushion)
62 482944 Weight Adjustment Kit
482948 Knob Kit
63 482952 Seat Adjustment, Track Set
64 482942 Shock Absorber Kit
