Page 13
13
Chapter 3
Connectors Description
This chapter provides a brief description of the SpacePC 1232 module’s connectors, with their
positions and functions.
Connectors Layout
In the following figure are shown the connectors with their layout and function/s.
J10
AC97 Audio
Serial 2
Serial 1
Parallel
Port
Auxiliary
Power
PS/2 Mouse
VGA
2x USB
Multifunction
Connector
Ethernet
IDE Led
J14
J6
J5
J3
J13
J4
J18
J11
J16
J17
U1
J19
JP10
J1 J2
NS
Geode Gx1
Processor
NS Geode
CS5530A
I/O
Companion
SSD
Figure 3.
Connectors layout
Note: in the previous figure, a red square pad indicates pin 1 of each connector.
