156
APPENDIX
DIP Switch 1
The following table shows all the possible settings for DIP Switch 1. All switch
settings, except for 1-7 and 1-8, are ON when the printer is shipped from the
factory.
*1
When the slip printer is used with independent mode, the baud rate cannot
be set to 19200 BPS. If DIP switch 1-1 is set to OFF and switch 1-2 is set to
ON, the baud rate becomes 9600 BPS.
Switch Parameter ON OFF
1-1
Baud Rate See table below
1-2
1-3 Data Length 8 bits 7 bits
1-4 Parity Check Disabled Enabled
1-5 Parity Selection Odd Even
1-6 Handshake DTR/DSR XON/XOFF
1-7 Serial I/F Pin 6 Reset Signal Active Inactive
1-8 Serial I/F Pin8 Reset Signal Active Inactive
Baud Rate Switch 1-1 Switch 1-2
2400BPS OFF OFF
4800BPS ON OFF
9600BPS ON ON
19200BPS
*1
OFF ON
