Instructions for the user

3. DESCRIPTION OF CONTROLS

3.1 The front panel

All the oven controls are grouped together on the front panel.

At first use or after a power outage, press the centre button

for 1

/ 2 seconds to enable the oven for cooking.

FUNCTIONS SWITCH KNOB

Turn the knob in either direction to select a
function from the following:

NO FUNCTION SELECTED

UPPER AND LOWER
HEATING ELEMENTS

LOWER HEATING ELEMENT
+ FAN-ASSISTED HEATING
ELEMENT

WIDE GRILL ELEMENT

FAN-ASSISTED HEATING
ELEMENT

NARROW GRILL ELEMENT

UPPER AND LOWER
HEATING ELEMENTS +
VENTILATION

GRILL ELEMENT +
VENTILATION

LOWER HEATING
ELEMENT + VENTILATION
