14.2.5.19 1588 Clock Target Reload/Add Low-DWORD Register (1588_CLOCK_TARGET_RELOAD_LO)
This read/write register combined with 1588 Clock Target Reload High-DWORD Register
(1588_CLOCK_TARGET_RELOAD_HI) form the 64-bit 1588 Clock Target Reload value. The 1588
Clock Target Reload is the value that is reloaded or added to the 1588 Clock Compare value when a
clock compare event occurs. Whether this value is reloaded or added is determined by the
Reload/Add
(RELOAD_ADD) bit of the 1588 Configuration Register (1588_CONFIG) . Refer to Chapter 11, "IEEE
1588 Hardware Time Stamp Unit," on page 154 for additional information.
Note: Both this register and the 1588 Clock Target Reload High-DWORD Register
(1588_CLOCK_TARGET_RELOAD_HI) must be written for either to be affected.
Offset: 188h Size: 32 bits
BITS DESCRIPTION TYPE DEFAULT
31:0 Clock Target Reload Low (CLOCK_TARGET_RELOAD_LO)
This field contains the low 32-bits of the 64-bit 1588 Clock Target Reload
value that is reloaded to the 1588 Clock Compare value. Alternatively, these
32-bits are added to the 1588 Clock Compare value when configured
accordingly. R/W 00000000h
