Smeg C6GVXI - Manual (Page 23)

Instructions for the user
94
11.EXTRAORDINARY MAINTENANCE
The oven may require extraordinary maintenance or replacement of parts subject to wear such as seals,
bulbs, and so on. The following instructions describe how to carry out these minor maintenance
operations.
Before any intervention that requires access to live parts, disconnect the power supply of the appliance.
11.1 Lubrication of gas oven taps and thermostat
Over time the gas taps and the gas oven thermostat may become difficult to turn and get blocked. Clean
them internally and replace the lubrication grease.
This operation must be carried out by a specialised technician.
11.2 Oven ventilation failure
To check on the operation of the ventilation the user must:
5 Light the gas oven, set the selector knob to the fan function (
) and wait until the internal oven
temperature reaches or goes above 120-130 °C;
6 With the gas oven off, set the selector knob to the thawing function ( ).
If there is a fault it can be detected if the ventilation does not start up when both operations are
performed.
In the case of a fault, do not attempt to repair it; instead, contact technical assistance.
11.3 Changing the light bulb
Remove the bulb protector A by turning it counterclockwise and change bulb B with a similar one (25 W).
Re-fit the bulb protector A.
Use only oven bulbs (T 300°C).
11.4 Removing the doors
Lift the levers B and take hold of the two sides of the door with
both hands near to the hinges A.
Raise the door to an angle of about 45° and remove it. To
reassemble, fit the hinges A into their grooves, then lower the
door into place and release the levers B.
11.5 Removing the door seal
To permit thorough cleaning of the oven, the seal may be removed.
Before removing the seal, take off the door as described above. Once
the door has been taken off, lift the tabs at the corners as shown in
the figure.
914773587/ H
