Control Codes PcOS Series 150 Programmer's Guide
Horizontal Motion
Page 16 Rev G 12/14/99
Horizontal Motion Control
There are several commands that can control the horizontal position of characters. Many
applications use space control to position fields. However, there is the ability to control character
position with horizontal tab stops. This is done by using the horizontal tab [HT] to move to those
tab stops.
Function Horizontal tab
ASCII [HT]
Hexadecimal 09H
Decimal <9>
IPCL &%HT
EPOS [HT]
Description This command inserts spaces in the print buffer up to the next tab stop.
The default tab locations are every 8 spaces.
Function Back space
ASCII [BS]
Hexadecimal 08H
Decimal <8>
IPCL &%BS
EPOS [BS]
Description This command prints the data in the print buffer and shifts the current
horizontal position by one character width to the left. If the current
position is at the left margin, the [BS] is ignored.
Function Set horizontal tab stops
ASCII [ESC] D
1
>
2
>
3
> ...
i
> 0
Hexadecimal 1BH 44H
1
>
2
>
3
> ...
i
> 00H
Decimal <27> <68>
1
>
2
>
3
> ...
i
> <0>
IPCL none
EPOS [ESC] D
1
>
2
>
3
> ...
i
> 0
Description This command sets tab stops at the character columns specified by .
The end of the setting is specified by a <0>. All previously set tabs will be
cleared by this command. There is no restore-defaults procedure other than
to respecify the tabs. The power up default is every 8 spaces, i.e., 9, 17, 25,
etc. Column sizes are in accordance with the current character pitch.
Setting tabs that are beyond the station width is possible. A [CR] will be
inserted if the tab is used. Printing will begin at the home position.
