5-32
DC3 D nl nh
Write in Position Specified by Dot in Ruled Line Buffer
Code
13
16
+ 44
16
+ nl + nh
Domain of
function
0
≤ nl ≤ 255
0
≤ nh ≤ 3
Function
Writes 1 in the specified position in the ruled line buffer.
The position is set at [(nh × 256 + nl) × dot pitch].
Details
• Regardless of the printable area, this function writes 1 in the selected ruled line
buffer.
• nh is valid only for the low 2 bits.
DC3 L nl nh ml mh
Write in Position Specified by Line in Ruled Line Buffer
Code
13
16
+ 4C
16
+ nl + nh + ml + mh
Domain of
function
0
≤ nl ≤ 255
0
≤ nh ≤ 3
0
≤ ml ≤ 255
0
≤ mh ≤ 3
Function
Writes 1 in the range from nhnl to mhml in the ruled line buffer.
0
≤ nhnl ≤ mhml ≤ 1023
nhnl
= (nh × 256 + nl) × dot pitch
mhml
= (mh × 256 + ml) × dot pitch
Details
• Regardless of the printable area, this function writes 1 in the selected ruled line
buffer.
• nh and mh are valid only for the low 2 bits.
