Specifications
Audio system
Sampling frequency 48 kHz (video sync)
Quantization 20 bits/sample
Input A/D quantization
20 bits/sample
Output D/A quantization
18 bits/sample
Frequency response 20 Hz to 20 kHz +0.5 dB/
-1.0 dB (reference level)
Dynamic range 95 dB minimum (1 kHz,
emphasis on)
Distortion 0.04% or less (1 kHz.
emphasis on, reference
level)
Crosstalk -80 dB or less (! kHz,
between channels)
Wow and flutter Below measurable limit
Headroom 2 0 d B ( 1 8 d B )
Emphasis Tl = 50 [is, T2 = 15 us (on/off
selectable in recording
mode)
(Using 20-bit D/A reference playback)
Frequency response 20 Hz to 20 kHz (0.5 dB/-l .0
dB (reference level)
Dynamic range 100 dB minimum (1 kHz,
emphasis on)
Distortion 0.03% or less (1 kHz,
emphasis on, reference
level)
Crosstalk -80 dB or less (1 kHz,
between channels)
Wow and flutter Below measurable limit
Inputs and outputs
Serial digital interface
SMPTE-259M/ITU-R BT.656
SDI IN (BNCxl) Serial digital component inpul
(including 4 audio
channels)
SDI OUT (BNCxl) Serial digital component
output (including 4 audio
channels)
Serial digital component input (including 4 audio
channels)
Analog audio input -60/-20/+4 dB switchable
High impedance, balanced
Video interface
VIDEO IN (BNCxl)
Analog composite video input
Camera interface
CAMERA (26-pinxl)
Analog component video
incut
Y: 1.0 V p-p, 75 (negative
sync)
R-Y/B-Y: 0.7 V p-p, 75
1.0 V p-p, 75
VIDEO OUT (BNCx2)
Analog composite video
output
1.0 V p-p, 75 selectable
text superimposition on
output 2 only
Audio interface
AUDIO IN (XLRx4)Analog audio input
-60/-20/+4 dB switchable
High impedance, balanced
AUDIO OUT (XLRx4)
Analog audio output
+4 dBm (0 dBm)
Low impedance, balanced
HEADPHONES (stereo standard jack xl)
- ) 7 d B u
EARPHONE (stereo minijack xl)
-17dBu
Time code interface
TC IN (BNC x l ) Time code input
0.5 to 18 V p-p, impedance
10 k, 10%
TC OUT (BNCxl) Time code output
1.0 V p-p (75 2.2 V p-p
( 1 0 k
Miscellaneous
REMOTE (9-pinxl)
Sony 9-pin protocol or RS-
232C interface
(switchable)
DC IN 1 2 V ( X L R x l )
Power supply from AC-550/
550CE AC Adaptor
A-4 Appendixes
