Section 2: Installation
GT Series Operator’s Manual Page 2-21
2.3 LOADING LABELS AND TAGS (CONT’D)
2.3.4 Adjusting the paper Sensor
Adjustment of the paper sensor is usually not necessary, but the procedure is described here.
1. Lift up the main cover. Make sure that the cover rests
firmly on the top of the printer so that it will not fall
forward and injure your hands.
2. The purple sensor unit is located just above the label
damper assembly. Slide it outwards to adjust its
position.
3. You can continue to load media by following the steps
in previous sections, or close the front cover.
Caution
• When closing the front cover, be careful not to injure your fingers due to a sudden release of the heavy cover.
Front Cover
Paper sensor
