– 90 –
APPENDIX
Data transmission rate (baud rate)
Baud rate Switch 6 Switch 7
1200 OFF OFF
2400 OFF ON
4800 ON OFF
9600 ON ON
DIP SW 2 (RS-422A interface only) All switch settings are ON when the
printer is shipped from the factory.
SW Function ON OFF
2-1
2-2 Device address See table below
2-3
2-4
2-5 When turning DC1, DC3 valid mode Select Deselect
the power on. DC1, DC3 invalid mode (Not used)
Addressable mode Deselect Select
2-6 Data composition XON/XOFF DTR
Mode DC1 Addressable mode DC1
DC3 #1 #2 #3 #4 #5 #6 #7 #8 #9 #10 #11 #12 #13 #14 DC3
invalid valid
mode mode
1 ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF
2 ON ON OFF OFF ON ON OFF OFF ON ON OFF OFF ON ON OFF OFF
3 ON ON ON ON OFF OFF OFF OFF ON ON ON ON OFF OFF OFF OFF
4 ON ON ON ON ON ON ON ON OFF OFF OFF OFF OFF OFF OFF OFF
