Star Micronics SP200F SERIES - Manual (Page 91)

– 88 –
APPENDIX
A-2. Interface Connections
The following is a basic example of interface connections. (For interface
connections, refer to the specifications for the respective interface.)
Fig. A-2 Example of interface connections
1 F-GND
N/C
RXD
RTS
N/C
N/C
S-GND
FAULT
DTR
F-GND
2 TXD
3 RXD
4 RTS
5 CTS
6 DSR
7 S-GND
8 DCD
20
1
2
3
4
5
6
7
14
20 DTR
Host computer
(D-sub 25 pin)
Printer side
(D-sub 25 pin)
1 F-GND
N/C
RXD
RTS
N/C
N/C
S-GND
FAULT
DTR
DCD
2 RXD
3 TXD
4 DTR
5 S-GND
6 DSR
7 RTS
8 CTS
9
1
2
3
4
5
6
7
14
20 RI
Host computer
(D-sub 9 pin)
Printer side
(D-sub 25 pin)
